Air Ring

MOLIPLAS Air Ring

MOLIPLAS's innovative air ring employs a stepper motor and air valve for precise air volume control, coupled with laser thickness measurement. This approach offers significant advantages over traditional heating methods, including faster response times, enhanced safety, greater efficiency, and reduced energy consumption. Precise air volume and temperature management minimizes film thickness deviations, and the integrated lift-up device boosts production by 20-40%.

Our Features

The modular design facilitates easy installation and future modifications

With the addition of a lift part mechanism, output can be increased by 20-40%.

A fast-response air volume control system effectively mitigates film thickness variations by 50% within an 8-minute cycle.

Advanced air volume control technology ensures compatibility with a wide range of film types, leading to a 10-15% improvement in production efficiency.

Air Ring with Automated Air Volume Control and Inline Scanning Thickness Gauge

Our expertly engineered automatic air ring, featuring precision air volume control and an integrated inline scanning thickness gauge, significantly enhances film thickness uniformity, enabling high-speed printing and lamination processes while increasing output and minimizing energy consumption.

Check More Demos

Parameters

Category for part of MOLIPLAS Air Ring at a glance

Model	Control unit	Lift-up
M-AIR-RING-300	48	Optional
M-AIR-RING-350	48	Optional
M-AIR-RING-400	48	Optional
M-AIR-RING-450	48	Optional
M-AIR-RING-500	60	Optional
M-AIR-RING-550	60	Optional
M-AIR-RING-600	60	Optional
